76PSB06T by grayhill
Image is representational - see mfr. specs

76PSB06T

Grayhill

The 76PSB06T is a 6-position, SPST Piano-DIP switch where the 'up' actuator position is open (off). ...

Datasheet
RoHS Compliant
TUBE Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 76PSB06T is a 6-position, RoHS compliant Piano-DIP switch from the Series 76 family. This through-hole component features a standard sealed base and a spring and ball contact mechanism, ensuring a mechanical life of 2,000 operations per position. Key electrical specifications include an initial contact resistance of 30 mΩ or less, a current carry rating of 4 A, and a dielectric strength of 750V AC. It is designed to function reliably across an operating temperature range of -40°C to +85°C. This switch is ideal for setting configurations and modes on printed circuit boards in various electronic applications.

Search Keywords: 76PSB06T

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
76PSB06T
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
15
Package Type:
TUBE
Body Orientation:
Straight
Actuator Style:
Piano
Actuator Length:
N/A
Number of Positions:
6
Pole Throw Configuration:
SPST
Mounting:
Through Hole
Terminal Type:
PC Pins
Contact Rating @ Voltage:
0.15@30VDC A
Contact Plating:
Gold/Nickel Barrier
Terminal Pitch:
2.54 mm

IN STOCK: 263

Ships today, if you order in

Minimum Order Quantity: 15

Multiple: 15

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
15
$6.48
60
$4.08
105
$3.86
255
$3.46
510
$3.25
1,005
$2.91
2,505
$2.78
5,010 +
$2.47
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
