76SB08ST by grayhill
Image is representational - see manufacturer specifications
Grayhill Authorized Distributor

76SB08ST

Switch DIP ON OFF SPST 8 Raised Rocker 0.15A 30VDC PC Pins 2000Cycles/SwitchCycles 2.54mm Thru-Hole Tube ...

View Datasheet Ask the Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The GRAYHILL part 76SB08ST is a DIP switch designed for easy ON/OFF switching functionality. It features a Single Pole Single Throw (SPST) configuration with 8 raised rockers for easy operation. This switch has a maximum current rating of 0.15A and a maximum voltage rating of 30VDC, making it suitable for a variety of applications. With PC pins for secure and reliable connection, this switch is built to withstand up to 2000 cycles/switch cycles. The 2.54mm thru-hole tube design ensures seamless integration and easy installation.

Search Keywords: 76SB08ST

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
76SB08ST
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536507000
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
12
Package Type:
TUBE
Body Orientation:
Straight
Actuator Style:
Raised Rocker
Actuator Length:
0.58 mm
Number of Positions:
8
Pole Throw Configuration:
SPST
Mounting:
Through Hole
Terminal Type:
PC Pins
Contact Rating @ Voltage:
0.15@30VDC A
Contact Plating:
Gold/Nickel Barrier
Terminal Pitch:
2.54 mm

IN STOCK: 12,792

Ships today, if you order in

Minimum Order Quantity: 12

Multiple: 12

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
12
$2.47
60
$2.22
108
$2.08
252
$1.92
504
$1.80
1,008
$1.71
2,508
$1.61
5,004 +
$1.50
Supplier's Standard Package
Log in for special pricing
