90B08ST by grayhill
Image is representational - see mfr. specs

90B08ST

Grayhill

Switch DIP ON OFF SPST 8 Recessed Slide 0.15A 30VDC PC Pins 2000Cycles/SwitchCycles 2.54mm Thru-Hole Tube ...

Datasheet
RoHS Compliant
TUBE Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 90B08ST is an 8-position thru-hole DIP switch designed for machine-insertable applications with a sealed molded base and optional top tape seal. It features high-pressure, reliable contacts with a contact resistance of =20 mO initially and =100 mO after life testing, ensuring consistent electrical performance. The switch has a length of 0.870 inches (22.1 mm) and is designed for 0.100 × 0.300 inch on-center hole spacing. With a mechanical life rating of 2,000 operations per switch position, a current carry rating of 3 A (maximum 20°C rise), and an operating temperature range of -40°C to +85°C, the 90B08ST is well-suited for industrial control panels, test equipment, and configuration applications where reliable switching and compact form factor are essential.

Search Keywords: 90B08ST

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
90B08ST
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Package Type:
TUBE
Body Orientation:
Straight
Actuator Style:
Recessed Slide
Actuator Length:
0 mm
Number of Positions:
8
Pole Throw Configuration:
SPST
Mounting:
Through Hole
Terminal Type:
PC Pins
Contact Rating @ Voltage:
0.15@30VDC A
Contact Plating:
Gold/Nickel Barrier
Terminal Pitch:
2.54 mm

IN STOCK: 960

Ships today, if you order in

Minimum Order Quantity: 20

Multiple: 20

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
20
$4.36
60
$4.16
260
$3.72
500
$3.51
1,000
$3.31
2,500
$3.18
5,000
$1.93
7,500 +
$1.87
Suppliers Standard Package
