M3786/4-3866GL by grayhill

M3786/4-3866GL

Grayhill

Switch Rotary SP3T 3 Flatted Shaft Solder Lug 5A 115VAC 28VDC ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The GRAYHILL M3786/4-3866GL is a high-quality rotary switch designed for a single pole triple throw (SP3T) configuration. It features a durable construction with a 3-flatted shaft that ensures easy and secure installation. The switch is suitable for various applications and can handle a maximum current of 5A and voltage of 115VAC or 28VDC. With solder lug terminals, it allows for convenient and reliable soldering connections. Whether you need to switch between different circuits or control different functions, the GRAYHILL M3786/4-3866GL provides reliable performance and versatility.

Search Keywords: M378643866GL

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
M3786/4-3866GL
RoHS:
Yes
HTS:
8536509020
COO:
US
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Number of Positions:
3
Pole Throw Configuration:
SP3T
Actuator Length:
11.1 mm
Dimension:
29.51 x 31.07 x 48.24 mm
Actuator Style/Diameter:
Flatted Shaft/6.35
Mounting:
Panel Mount
Body Orientation:
Straight
Terminal Type:
Solder
Angle of Throw:
45 °
Contact Rating @ Voltage:
5@115VAC A

IN STOCK: 15

Ships today, if you order in

Factory Lead-Time 12 Weeks

Price (CAD)

Qty
Unit Price
1
$144.326
5
$138.736
10
$135.780
15
$133.055
25
$131.048
50 +
$129.089
Log in for special pricing
Click for Quote
