M3786/4-5373 by grayhill

M3786/4-5373

Grayhill

Switch Rotary DP3T 3 Flatted Shaft Solder Lug 1A 115VAC 115VDC ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The GRAYHILL M3786/4-5373 is a high-quality rotary switch with a Double Pole Triple Throw (DP3T) configuration, perfect for applications requiring multiple switching options. This switch features a 3-flatted shaft design and solder lug terminals for easy installation. With a 1A rating at both 115VAC and 115VDC, this switch is suitable for a wide range of industrial and electronic devices. Trust in the reliability and durability of GRAYHILL switches for your next project.

Search Keywords: M378645373

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
M3786/4-5373
RoHS:
Yes
HTS:
8536509020
COO:
US
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Number of Positions:
3
Pole Throw Configuration:
DP3T
Actuator Length:
11.1 mm
Dimension:
26.97 x 26.97 x 65.81 mm
Actuator Style/Diameter:
Flatted Shaft/6.35
Mounting:
Panel Mount
Body Orientation:
Straight
Terminal Type:
Solder
Angle of Throw:
36 °
Contact Rating @ Voltage:
1@115VAC 28VDC A

IN STOCK: 1

Can Ship immediately

On Order: 10   can ship 2/16/26

MOQ for out of Stock Qty: 3

Factory Lead-Time 12 Weeks

Price (CAD)

Qty
Unit Price
1
$239.970
3
$237.597
5
$228.669
8
$227.536
10 +
$199.804
