M80-4143898

Name: M80-4143898
Brand: Harwin
SKU: 55484852
Price: 40.4 USD
Availability: InStock

Wtb Housing Connector, 38Pos, 2Row, 2Mm Rohs Compliant: Yes |Harwin M80-4143898 ...

View Datasheet

Ask the Datasheet

RoHS Compliant

DESCRIPTION

The M80-4143898 is a female T-contact J-TEK crimp connector with hex socket jackscrew designed for secure modular interconnect applications. The housing is constructed from glass-filled PPS material with UL94V-0 flame rating in black, providing excellent chemical resistance and durability. It features a maximum height of 7.55 mm and is available in configurations from 4 to 50 positions (even numbers only), with dimensions calculated based on contact count: DIM A = total positions + 10.0 mm, DIM B = total positions + 5.00 mm, and DIM C = total positions - 2.00 mm. The connector operates across a wide temperature range of -55 °C to +125 °C and is supplied with M80-2060005 contacts (sold separately). This connector is ideal for aerospace, defense, and industrial applications requiring reliable, compact interconnection with tool-free mating via the hex socket jackscrew.

Product Highlights:

Potential Applications:

Search Keywords: M804143898

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Harwin

Part No:

M80-4143898

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536904000

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
