713-5 by hasco relays
Image is representational - see mfr. specs

713-5

Hasco Relays

Reed Relays 5VDC 500Ohm 0.5A SPST-NO (28.57x7.62x10.66)mm THT Dry ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 713-5 is a 5 VDC reed relay from the 700 Series designed for general-purpose switching in industrial and electronic control systems. It features a nominal coil voltage of 5 VDC with a pick-up voltage of 3.75 VDC maximum and drop-out voltage of 0.5 VDC minimum, with a coil resistance of 500 O. The relay is rated for AC 50 VA and DC 50 W maximum at 300 VAC and 350 VDC, with a 600 VDC breakdown voltage across contacts. It delivers fast switching performance with an operate time of 0.5 ms and release time of 0.2 ms, an initial contact resistance of 150 mO, and an insulation resistance of 1000 MO. The relay operates reliably across -40 °C to +85 °C, withstands 20 G vibration (10–2000 Hz), and is rated for 5×107 operations at no load or 3×106 operations at rated load. Its epoxy-molded construction and RoHS compliance make it suitable for telecommunications, industrial control, and consumer electronics applications requiring compact, fast-switching relay performance.

Search Keywords: 7135

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Hasco Relays
Part No:
713-5
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Type:
Dry
DC Coil Voltage:
5 V
Contact Arrangement:
SPST-NO
Maximum AC Switching Voltage:
300 V
Maximum DC Switching Voltage:
350 V
Maximum Carry Current:
2.5 A
Maximum Switching Current:
0.5 A
Maximum Switching Power:
50,50 W|VA
Package Type:
SIP
Terminal Type:
PC Pin
Mounting:
Through Hole

IN STOCK: 2,294

Ships today, if you order in

Minimum Order Quantity: 10

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
10
$6.32
25
$3.78
100
$1.79
250
$1.58
500
$1.45
1,000
$1.43
2,500
$1.30
2,780 +
$1.23
