103SR13A-2 by honeywell

103SR13A-2

Honeywell

Honeywell Magnetic Value-added Hall-effect Sensor: 103SR Series, Unipolar Hall-effect Digital Position Sensors, 4.5 to 24 Vdc supply voltage, Sealed, 15/32-32 UNS-2A cylindrical aluminum threaded housing, Digital sinking output,Two hex nuts, 1000 mm [39.4 in] 22 gauge PVC insulated conductors with black molded PVC jacket. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The Honeywell part 103SR13A-2 is a high-performance magnetic value-added Hall-effect sensor from the 103SR series. This sensor operates on a supply voltage of 4.5 to 24 Vdc and provides a reliable and accurate digital position sensing solution. Featuring a sealed 15/32-32 UNS-2A cylindrical aluminum threaded housing, this sensor is built to withstand harsh environments and provide long-lasting performance. The digital sinking output ensures easy integration into existing systems.The sensor comes with two hex nuts for secure mounting and includes 1000mm (39.4 inches) of 22-gauge PVC insulated conductors with a black molded PVC jacket. This makes installation and wiring hassle-free.Overall, the Honeywell 103SR13A-2 is an ideal choice for applications that require precise and robust digital position sensing.

Product Highlights:

  • Current sinking ouput
  • Rugged, sealed threaded aluminum housing NEMA 3, 3R, 3S, 4, 12 and 13 requirements
  • 22 AWG, 1 m [39.4 in] jacketed cable, color coded, PVC insulated conductors and jacket
  • Adjustable mounting

Search Keywords: 103SR13A2

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
103SR13A-2
RoHS:
Yes
HTS:
85365090
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Magnetic Type:
Unipolar
Maximum Output Current:
20 mA
Mounting:
Panel
Minimum Magnetic Sensor Release Point:
200 Gs
Maximum Magnetic Sensor Operating Point:
495 Gs
Output Type:
0.4 V
Output Driver:
NPN
Product Type:
Digital
Dimension:
25.4mm x 12mm dia
Typical Operating Supply Voltage:
4.5 to 24 V
Termination Type:
Wire Leads
Operating Temperature:
-40 to 100 °C

IN STOCK: 207

Ships today, if you order in

MOQ for out of Stock Qty: 25

Factory Lead-Time 28 Weeks

Price (USD)

Qty
Unit Price
1
$69.020
5
$60.296
10
$57.968
25
$56.835
50
$55.723
75
$55.445
100 +
$55.136
Suppliers Standard Package
