Image is representational - see manufacturer specifications
Honeywell Authorized Distributor

11TL1-3D

Toggle Switch - SPDT - On-On - 15A, 125VAC - 26.67mm Locking Lever Actuator - Non-Illuminated - Sealed - Solder Turret - Panel Mount. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 11TL1-3D from HONEYWELL is panel mount single pole double throw (SPDT) toggle switch with On-On switch function and solder turret termination. This sealed switch has non-illuminated 26.67mm long locking lever actuator. The 11TL1-3D has 15A current rating and 125VAC voltage rating. Dimensions of this switch are: 28.45 mm L x 15.75 mm D x 74.93 mm H. Operating temperature range is from -65°C to 71°C.

Product Highlights:

  • Qualified to MIL-S-3950
  • Environment-proof sealing
  • 1,2, and 4 pole circuitry
  • Standard and pull-to-unlock levers
  • 2 and 3 position, maintained and momentary toggle action
  • Temperature range: -85 F to +160 F
  • Completely sealed switching chamber
  • Step-design case provides added space between terminals to help prevent shorting
  • UL recognized, CSA certified
  • CE approved

Potential Applications:

  • Industrial machinery and equipment
  • Military and commercial aviation
  • Construction equipment
  • Test instruments
  • Agricultural machinery
  • Process control
  • Medical instrumentation

Search Keywords: 11TL13D

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
11TL1-3D
Alias/AKA:
MS27737-23D
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
85365080
COO:
US
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Pole Throw Configuration:
1P2T (SPDT)
Switch Configuration:
On None On
Contact Rating @ Voltage:
745.7@(CSA/UL) A
Actuator Style:
Locking Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Solder
Dimension:
28.45 x 15.75 x 74.93 mm
Operating Temperature:
-65 to 71 °C

IN STOCK: 132

Can Ship immediately

MOQ for out of Stock Qty: 13

Factory Lead-Time 21 Weeks

Price (USD)

Qty
Unit Price
1
$135.27
5
$111.61
10
$108.11
13
$103.66
25
$102.63
38
$101.61
50 +
$100.61
