11TL1-8 by honeywell
Image is representational - see manufacturer specifications
Honeywell Authorized Distributor

11TL1-8

MICRO SWITCH™ Toggle Switches: TL Series, Single Pole Double Throw (SPDT) 2 Position (Mom. On - On), Solder Turret Terminals, Standard Lever, Military Part Number MS27734-26 ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

MICRO SWITCH™ Toggle Switches: TL Series, Single Pole Double Throw (SPDT) 2 Position (Mom. On - On), Solder Turret Terminals, Standard Lever, Military Part Number MS27734-26

Product Highlights:

  • Qualified to MIL-S-3950
  • Environment-proof sealing
  • 1,2, and 4 pole circuitry
  • Standard and pull-to-unlock levers
  • 2 and 3 position, maintained and momentary toggle action
  • Temperature range: -85 F to +160 F
  • Completely sealed switching chamber
  • Step-design case provides added space between terminals to help prevent shorting
  • UL recognized, CSA certified
  • CE approved

Potential Applications:

  • Industrial machinery and equipment
  • Military and commercial aviation
  • Construction equipment
  • Test instruments
  • Agricultural machinery
  • Process control
  • Medical instrumentation

Search Keywords: 11TL18

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
11TL1-8
Alias/AKA:
MS27734-26
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536500000
COO:
US
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Pole Throw Configuration:
1P2T (SPDT)
Switch Configuration:
On None On
Contact Rating @ Voltage:
372.85@(CSA/UL) A
Actuator Style:
Round Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Solder
Dimension:
28.45 x 15.75 x 63.37 mm
Operating Temperature:
-65 to 72 °C

IN STOCK: 50

Ships today, if you order in

MOQ for In Stock Qty: 3

MOQ for out of Stock Qty: 3

Factory Lead-Time 19 Weeks

Price (USD)

Qty
Unit Price
3
$99.08
5
$98.83
10
$98.58
13
$98.33
25
$62.93
38
$49.17
50 +
$48.18
