12TL1-31M by honeywell
Image is representational - see manufacturer specifications
Honeywell Authorized Distributor

12TL1-31M

MICRO SWITCH™ Toggle Switches: TL Series, Double Pole Double Throw (DPDT) 2 Position, Half Throw (On - On), Solder Turret Terminals, Locking Lever (Locked Out Of And Into Extreme Position, Opposite Keyway), Military Part Number MS27738-33M ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Discontinued
Certificate of Compliance

DESCRIPTION

The HONEYWELL 12TL1-31M is a MICRO SWITCHâ„¢ toggle switch from the TL Series. It features a double pole double throw (DPDT) configuration with 2 positions and a half throw (On - On) functionality. The switch is equipped with solder turret terminals for secure and reliable connections. It also comes with a locking lever that can be locked out of and into extreme positions, opposite the keyway. This switch is designed to meet military standards and its military part number is MS27738-33M.

Search Keywords: 12TL131M

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
12TL1-31M
Alias/AKA:
MS27738-33M
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509040
COO:
US
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Pole Throw Configuration:
2P2T (DPDT)
Switch Configuration:
On None On
Contact Rating @ Voltage:
745.7@(CSA/UL) A
Actuator Style:
Locking Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Solder
Dimension:
34.04 x 23.11 x 75.95 mm
Operating Temperature:
-65 to 72 °C
Life Cycle:
Discontinued
  This product is discontinued, but still in stock

IN STOCK: 19

Ships today, if you order in

Price (USD)

Qty
Unit Price
1
$102.19
5
$87.27
10
$78.69
20
$74.38
50
$72.40
100 +
$71.44
