12TW1-1A by honeywell

12TW1-1A

Honeywell

MICRO SWITCH™ Miniature Toggle Switches: TW Series, Double Pole Double Throw (DPDT) 3 Position (On - Off - On), Solder Terminals, 15/32 Inch Bushing, Mushroom-Style Locking Lever (Locked In Three Positions), Military Part Number MS27721-21-1A ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The HONEYWELL part 12TW1-1A is a high-quality MICRO SWITCH„¢ Miniature Toggle Switch. This particular model belongs to the TW Series and features a Double Pole Double Throw (DPDT) 3 Position design, allowing for three distinct settings: On, Off, and On. The switch is equipped with durable solder terminals for secure and reliable connection. It also includes a 15/32 Inch Bushing for effortless installation. The unique Mushroom-Style Locking Lever has a locking mechanism that ensures it stays firmly in any of the three positions, preventing accidental switching. This switch is designed to meet military standards and is assigned the part number MS27721-21-1A, guaranteeing its exceptional quality and reliability.

Product Highlights:

  • Qualified to MIL-S-83731
  • Save space and weight
  • SPDT and DPDT circuitry
  • Temperature range: -85 F to +160 F (-65 C to +71 C)
  • Sealed bushing versions
  • Choice of in. or 15/32 in. bushing
  • Color tab available on 15/32 in. bushing
  • UL recognized

Potential Applications:

  • Industrial machinery and equipment
  • Military and commercial aviation
  • Construction equipment
  • Test instruments
  • Agricultural machinery
  • Process control
  • Medical instrumentation

Search Keywords: 12TW11A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
12TW1-1A
RoHS:
Yes
HTS:
85365000
COO:
US
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Bag
Pole Throw Configuration:
2P2T (DPDT)
Switch Configuration:
On Off On
Contact Rating @ Voltage:
5 A
Actuator Style:
Locking Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Solder
Dimension:
14.7 x 13.7 x 62.4 mm
Operating Temperature:
-65 to 71 °C

IN STOCK: 0

Factory Lead-Time 25 Weeks

Price (CAD)

Qty
Unit Price
1
$226.945
5
$203.052
10
$194.308
15
$191.599
25
$189.935
50 +
$188.689
