12TW1-2D by honeywell
Image is representational - see mfr. specs

12TW1-2D

Honeywell

MICRO SWITCH™ Miniature Toggle Switches: TW Series, Double Pole Single Throw (DPST) 2 Position (Off - On), Solder Terminals, 15/32 Inch Bushing, Mushroom-Style Locking Lever (Locked Out Of Center Position), Military Part Number MS27721-22-1D ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The HONEYWELL part 12TW1-2D is a high-quality MICRO SWITCH„¢ Miniature Toggle Switch from the TW Series. It is a Double Pole Single Throw (DPST) switch with a 2 Position (Off - On) configuration and solder terminals for easy installation. The switch features a 15/32 Inch Bushing and a Mushroom-Style Locking Lever that ensures secure and reliable operation. This specific model, identified by the Military Part Number MS27721-22-1D, is designed for military applications and meets rigorous standards for durability and performance.

Search Keywords: 12TW12D

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
12TW1-2D
Alias/AKA:
MS27721-22-1D
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
85365030
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Pole Throw Configuration:
2P1T (DPST)
Switch Configuration:
OFF None ON
Contact Rating @ Voltage:
5 A
Actuator Style:
Locking Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Solder
Dimension:
14.61 x 13.59 x 62.48 mm
Operating Temperature:
-65 to 71 °C

IN STOCK: 0

MOQ for out of Stock Qty: 13

Factory Lead-Time 34 Weeks

Price (USD)

Qty
Unit Price
13
$499.09
25
$273.94
38
$185.92
50 +
$182.20
