151ML1-E1 by honeywell
Image is representational - see mfr. specs

151ML1-E1

Honeywell

The 151ML1-E1 is an explosion-proof enclosed limit switch with a roller lever actuator and a double-throw, double-break contact arrangement. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 151ML1-E1 is an enclosed limit switch designed for reliable operation in hazardous environments. It features a two-circuit, double-throw, double-break contact arrangement rated for 10A at up to 480 VAC and DC loads up to 0.8A at 115 VDC. The switch has a maximum operating force of 3 lbs, a maximum pretravel of 15°, and a minimum overtravel of 60°. Listed by UL for Class 1 (Groups C, D) and Class 2 (Groups E, F, G) atmospheres, this switch is ideal for applications requiring robust, explosion-proof position sensing.

Search Keywords: 151ML1E1

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
151ML1-E1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
85365030
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Type:
Enclosed
Actuator Style:
Side Rotary with Roller Lever
Pole Throw Configuration:
N/A
Switch Configuration:
N/A
Operating Force:
13.34 N
Dimension:
53.85 x 82.55 x 189.55 mm
Maximum Current Rating:
10@480VAC A
Terminal Type:
Conduit
NEMA Standard as Enclosure Rating:
N/A
Body Orientation:
Right Angle

IN STOCK: 12

Ships today, if you order in

Factory Lead-Time 23 Weeks

Price (USD)

Qty
Unit Price
1
$3,217.48
3
$3,209.44
5 +
$3,201.42
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
