1CPSA1
HoneywellThis Cable Pull Safety Switch from Honeywell comes from their 1CPS Series and is designed to allow emergency stop protection for exposed conveyor lines. The switch features a cable tension window with an indicating line at its midpoint to indicate proper cable tension. The switch’s housing is made from die-cast zinc and the Cable Pull Safety Switch is perfect for conveyor applications that experience wide temperature swings. ...
DESCRIPTION
Introducing the HONEYWELL 1CPSA1 Cable Pull Safety Switch, a reliable solution for emergency stop protection on exposed conveyor lines. Designed as part of the 1CPS Series, this switch features a cable tension window with an indicating line, ensuring proper cable tension at all times. The switch€™s sturdy die-cast zinc housing guarantees durability and allows it to withstand wide temperature swings, making it ideal for conveyor applications in various environments. Trust HONEYWELL for superior safety and reliability with the 1CPSA1 Cable Pull Safety Switch.
Product Highlights:
- Direct opening actions of normally closed contacts
- Choice of 1NC/1NO, 2NC/2NO or 3NC/1NO, 4NC contact configurations
- Typical cable span of 76 m [250 ft)] in an environment with a temperature change of 17 C [ 30 F] an endspring is used (longer spans are possible depending upon temperature change and installtion
- Large wiring cavity with straight-through wiring
- 24 Vdc or 120 Vac single red high intensity LED status indicator light available
- Gold-plated or silver contacts available
- Die-cast zinc housing
- Optional hardware packs available
Search Keywords: 1CPSA1
SPECIFICATIONS
IN STOCK: 27
Ships today, if you order in
Factory Lead-Time 15 Weeks
Datasheet
