1LS131 by honeywell

1LS131

Honeywell

MICRO SWITCH™ General Purpose Limit Switches: LS Series, Epoxy-Coated Zinc Housing, Non Plug-in Body Style, Side Rotary, Fixed Length Roller Lever, Ø 19 mm x 6 mm [0.75 in x 0.24 in] Steel Roller, Low Pretravel, Low Operating Torque, 1NC 1NO Single Pole Double Throw (SPDT) Snap Action, Double Break, 10 A 120, 240, or 480 Vac, 0.5 in - 14 NPT Conduit, Operating Temperature: -29 °C to 71 °C [-20 °F to 160 °F], NEMA 1, 3, 4, 6 and 13 ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The HONEYWELL part 1LS131 is a MICRO SWITCHA„¢ General Purpose Limit Switch designed for a wide range of applications. It features an epoxy-coated zinc housing for durability and a non plug-in body style. The switch has a side rotary design and is equipped with a fixed length roller lever, measuring A˜ 19 mm x 6 mm [0.75 in x 0.24 in], made of steel. With low pretravel and low operating torque, this limit switch provides accurate and reliable performance. It offers 1NC 1NO single pole double throw (SPDT) snap action with double break contacts. The 1LS131 has a rating of 10 A and can operate at voltages of 120, 240, or 480 Vac. It comes with a 0.5 in - 14 NPT conduit for easy installation. The operating temperature range is -29 A°C to 71 A°C [-20 A°F to 160 A°F], making it suitable for various environments. This limit switch is compliant with NEMA 1, 3, 4, 6, and 13 standards, ensuring its reliability and functionality in different settings.

Product Highlights:

  • Mode of operation is field adjustable
  • NEMA 1, 3, 4, 6, and 13
  • Wide choice of heads and actuators
  • Variety of operating characteristics
  • Captive screws
  • UL and CSA approved parts available

Potential Applications:

  • Machine tools
  • Conveyors
  • Material handling
  • Metal fabrication equipment
  • Lift trucks

Search Keywords: 1LS131

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
1LS131
RoHS:
Yes
HTS:
8536509040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Type:
Enclosed
Actuator Style:
Side Rotary with Roller Lever
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Operating Force:
N/A
Dimension:
39.88 x 53.19 x 93.98 mm
Maximum Current Rating:
N/A
Terminal Type:
Conduit
NEMA Standard as Enclosure Rating:
1, 3, 4, 6, 13
Body Orientation:
Right Angle

IN STOCK: 39

Ships today, if you order in

Factory Lead-Time 7 Weeks

Price (CAD)

Qty
Unit Price
1
$510.582
3
$500.154
5 +
$489.190
