1LS1-L

MICRO SWITCH™ General Purpose Limit Switches: LS Series, Epoxy-Coated Zinc Housing, Non Plug-in Body Style, Side Rotary, Fixed Length Roller Lever, Ø 19 mm x 6 mm [0.75 in x 0.24 in] Steel Roller, 1NC 1NO Single Pole Double Throw (SPDT) Snap Action, Double Break, 10 A 125, 250, or 480 Vac, 0.5 in - 14 NPT Conduit, Operating Temperature: -29 °C to 71 °C [-20 °F to 160 °F], NEMA 1, 3, 4, 6 and 13, Agency Approvals: UL, CSA ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The MICRO SWITCH„¢ General Purpose Limit Switches are built with durability and reliability in mind. The LS Series features an epoxy-coated zinc housing that ensures protection against harsh environments. This particular model, the 1LS1-L, offers a non plug-in body style with a side rotary design. It has a fixed length roller lever measuring 19 mm x 6 mm [0.75 in x 0.24 in] and features a steel roller for smooth operation. With a 1NC 1NO single pole double throw (SPDT) snap-action configuration, this limit switch provides double break switching capability. It has a current rating of 10 A at 125, 250, or 480 Vac. The 0.5 in - 14 NPT conduit allows for easy installation and provides secure electrical connections. Operating temperature ranges from -29 °C to 71 °C [-20 °F to 160 °F], making it suitable for a wide range of applications. This limit switch is designed to meet NEMA 1, 3, 4, 6, and 13 standards for protection and is UL and CSA approved for safety and reliability.

Product Highlights:

  • Mode of operation is field adjustable
  • NEMA 1, 3, 4, 6, and 13
  • Wide choice of heads and actuators
  • Variety of operating characteristics
  • Captive screws
  • UL and CSA approved parts available

Potential Applications:

  • Machine tools
  • Conveyors
  • Material handling
  • Metal fabrication equipment
  • Lift trucks

Search Keywords: 1LS1L

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
1LS1-L
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
85365080
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
10
Type:
Enclosed
Actuator Style:
Side Rotary with Roller Lever
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Operating Force:
N/A
Dimension:
57.91 mm
Maximum Current Rating:
0.8 A
Terminal Type:
Conduit
NEMA Standard as Enclosure Rating:
1, 3, 4, 6, 13
Body Orientation:
Right Angle
