1SE3 by honeywell

1SE3

Honeywell

MICRO SWITCH™ Miniature Environmentally Sealed Basic Switches: SE Series, Single Pole Normally Open (SPNO), 5 A at 250 Vac, Stainless Steel Pin Plunger, (2) 305 mm [12 in] Lead Wire Termination (20 Gage), -53 °C to 105 °C [-65 °F to 221 °F] Temperature Range ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

A Snap Action Switch is a type of momentary contact micro switch which operates at rapid speed as it takes very little force or stimulus to operate. These are highly sensitive switches that respond to very small movements and can rapidly change from one contact position to the other. The SE series enclosed basic micro switches are environment-sealed with a corrosion-resistant aluminum housing to seal precision switch contacts from contamination. They are mostly used in aircraft, ordinance, and moist or dusty industrial environments.

1SE3 Snap Action Switch from Honeywell comes with a choice of actuation and power load switching capability to 7 A. This Honeywell Switch is packaged nicely for convenience.

Product Highlights:

  • Watertight seal per MIL-PRF-8805
  • Very small package size
  • Power load switching capability to 7 A
  • Maximum AC Voltage Rating: 250 V
  • Maximum DC Voltage Rating: 30 V
  • Temperature tolerance to 105 °C [221 °F]
  • High temperature construction for use to 149 °C [300 °F]
  • Choice of actuation

Potential Applications:

  • Aircraft
  • Ordinance
  • Moist or dusty industrial environments

Search Keywords: 1SE3

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
1SE3
RoHS:
Yes
HTS:
85365009
COO:
US
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Mounting:
Through Hole
Pole Throw Configuration:
SPST
Switch Configuration:
N.O.
Actuator Material/Style:
Steel/Pin Plunger
Contact Rating @ Voltage:
5@250VAC 28VDC A
Maximum Movement Differential:
0.1 mm
Operating Force:
4.73 N
Termination Style:
Wire Lead
Dimension:
22.25 x 8.79 x 18.92 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 110

Ships today, if you order in

Factory Lead-Time 18 Weeks

Price (CAD)

Qty
Unit Price
1
$268.896
3
$264.701
5
$262.939
10 +
$212.698
Log in for special pricing
Click for Quote
