1SX12-T by honeywell
Image is representational - see mfr. specs

1SX12-T

Honeywell

MICRO SWITCH™ Subminiature Basic Switches: SX Series, Single Pole Double Throw (SPDT), 4 A at 250 Vac, Pin Plunger Actuator, Solder Termination ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The HONEYWELL part 1SX12-T is a reliable and versatile subminiature basic switch from the MICRO SWITCH„¢ SX Series. It features a single pole double throw (SPDT) configuration, making it suitable for a variety of applications. With a robust construction, this switch is capable of handling up to 4 A at 250 Vac, ensuring long-lasting performance. The pin plunger actuator provides precise and reliable operation, while the solder termination simplifies the installation process. Whether used in industrial equipment, appliances, or automotive applications, the 1SX12-T offers exceptional durability and control.

Product Highlights:

  • Long operating life
  • Elongated mounting hole for easier, more accurate mounting
  • Choice of actuation (plunger, as well as a variety of integral and auxiliary actuators)
  • Choice of electrical termination (solder, quick connect, PCB)
  • Choice of operating characteristics
  • Optional series constructions available (gold contacts for low energy switching, bifurcated gold contacts for maximum reliability, power load switching capability to 7 A)
  • MIL-PRF-8805 qualified listings available

Potential Applications:

  • Aerospace
  • Appliances
  • Vending machines
  • Timing devices
  • Office equipment
  • Computer/business equipment
  • Test instruments
  • Medical/dental equipment
  • Communications equipment
  • HVAC equipment
  • Manually operated devices
  • Valves

Search Keywords: 1SX12T

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
1SX12-T
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
85365080
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Plastic/Pin Plunger
Contact Rating @ Voltage:
7 A
Maximum Movement Differential:
0.051 mm
Operating Force:
1.39 N
Termination Style:
Solder
Dimension:
12.7 x 5.1 x 12.73 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 609

Ships today, if you order in

Factory Lead-Time 17 Weeks

Price (USD)

Qty
Unit Price
1
$37.28
5
$35.02
10
$32.05
25
$30.53
50
$29.86
100
$29.67
250 +
$29.53
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
