1XE201 by honeywell

1XE201

Honeywell

MICRO SWITCH™ Subminiature Environmentally Sealed Basic Switches: XE Series, Single Pole Double Throw (SPDT), 7 A at 28 Vdc, Stainless Steel Enclosure, (3) 305 mm [12 in] Lead Wire Termination (20 Gage), -53 °C to 105 °C [-65 °F to 221 °F] Temperature Range, Military Part Number MS27994-4 ...

Datasheet
RoHS Non-Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The HONEYWELL part 1XE201 is a MICRO SWITCH™ subminiature environmentally sealed basic switch from the XE Series. It features a single pole double throw (SPDT) configuration with a current rating of 7 A at 28 Vdc, making it suitable for a wide range of applications. The switch is housed in a stainless steel enclosure, providing durability and resistance to harsh environments. It is equipped with (3) 305 mm [12 in] lead wires terminated with 20-gauge connectors, making installation easy. The switch has a temperature range of -53 °C to 105 °C [-65 °F to 221 °F], allowing it to operate reliably in extreme conditions. It is also designed to meet the specifications of the military part number MS27994-4, ensuring high quality and performance.

Product Highlights:

  • Very small package size
  • Power load switching capability to 7 A
  • Temperature tolerance to 105 C [221 F]
  • High temperature construction for use to 149 C [300 F]
  • Watertight seal per MIL-S-8805, enclosure design symbol 3
  • Choice of actuation

Potential Applications:

  • Aircraft
  • Ordinance
  • Moist or dusty industrial environments

Search Keywords: 1XE201

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
1XE201
RoHS:
No
HTS:
8536509065
COO:
US
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Steel/Pin Plunger
Contact Rating @ Voltage:
7@115VAC 28VDC A
Maximum Movement Differential:
0.13 mm
Operating Force:
4.73 N
Termination Style:
Wire Lead
Dimension:
15.65 x 8.03 x 18.92 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 180

Can Ship immediately

Factory Lead-Time 4 Weeks

Price (CAD)

Qty
Unit Price
1
$255.314
3
$249.556
5
$245.881
10 +
$239.802
