2CPSC1A1 by honeywell

2CPSC1A1

Honeywell

Switch Safety Interlock N.O./N.C. 4PST Eyelet Pull 0.05A 250VAC 60VDC 177.93N Screw Mount Conduit 1000000Cycles ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The HONEYWELL part 2CPSC1A1 is a high-quality switch safety interlock designed with a reliable N.O./N.C. four-pole single throw configuration. Featuring an eyelet for easy pull operation, this interlock has a robust current rating of 0.05A at 250VAC and 60VDC, ensuring optimal performance in various applications. With a screw mount for secure installation and a sturdy conduit, it offers exceptional durability. This interlock can withstand up to 1000000 cycles, providing a long-lasting and dependable solution for demanding industrial environments.

Product Highlights:

  • Positive opening operation of normally closed contacts
  • Choice of 2NC/2NO or 3NC/1NO contact configurations
  • Maximum cable length in a single direction is 76 m (250 ft) for a combined length of 152 m (500 ft) in dual directions
  • Choice of three actuator configurations
  • Removable contact block version available
  • Large wiring cavity with straight-through wiring
  • 24 Vdc or 120 Vac bright, multi-cluster LED status indicator light available
  • Gold-plated contacts are standard
  • Die-cast zinc housing
  • Optional hardware packs available

Search Keywords: 2CPSC1A1

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
2CPSC1A1
RoHS:
Yes
HTS:
8536509055
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Type:
Cable Pull
Actuator Style:
Eyelet Pull
Pole Throw Configuration:
4PST
Maximum Current Rating:
0.05 A
Terminal Type:
Conduit
Operating Temperature:
-40 to 80 °C
IP Rating:
IP67
Dimension:
323.85 x 79.8 x 165.1 mm
Switch Configuration:
N.O./N.C.
Body Orientation:
Straight

IN STOCK: 4

Can Ship immediately

Factory Lead-Time 21 Weeks

Price (CAD)

Qty
Unit Price
1
$1,949.899
3
$1,863.813
5 +
$1,854.485
Log in for special pricing
Click for Quote
