2TL1-10N by honeywell

2TL1-10N

Honeywell

MICRO SWITCH™ Toggle Switches: TL Series, Double Pole Double Throw (DPDT) 3 Position, Special Circuitry (On - On - On), Screw Terminals, Locking Lever (Locked Out Of Extreme Position, Opposite Keyway), Military Part Number MS27408-4N ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The HONEYWELL 2TL1-10N is a MICRO SWITCHâ„¢ Toggle Switch from the TL Series, featuring a Double Pole Double Throw (DPDT) design with 3 positions and special circuitry (On - On - On). This rugged switch is equipped with screw terminals for easy installation and a locking lever that is locked out of the extreme position, with an opposite keyway for added security. The military part number MS27408-4N ensures high quality and reliability for use in demanding applications.

Product Highlights:

  • Qualified to MIL-S-3950
  • Environment-proof sealing
  • 1,2, and 4 pole circuitry
  • Standard and pull-to-unlock levers
  • 2 and 3 position, maintained and momentary toggle action
  • Temperature range: -85 F to +160 F
  • Completely sealed switching chamber
  • Step-design case provides added space between terminals to help prevent shorting
  • UL recognized, CSA certified
  • CE approved

Potential Applications:

  • Industrial machinery and equipment
  • Military and commercial aviation
  • Construction equipment
  • Test instruments
  • Agricultural machinery
  • Process control
  • Medical instrumentation

Search Keywords: 2TL110N

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
2TL1-10N
RoHS:
Yes
HTS:
85365090
COO:
US
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Pole Throw Configuration:
1P3T (SP3T)
Switch Configuration:
ON ON ON
Contact Rating @ Voltage:
745.7 A
Actuator Style:
Locking Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Screw
Dimension:
33.5mm x 22.6mm x 72.9mm
Operating Temperature:
-65 to 71 °C

IN STOCK: 35

Can Ship immediately

On Order: 52   can ship 1/19/26

MOQ for out of Stock Qty: 13

Factory Lead-Time 35 Weeks

Price (CAD)

Qty
Unit Price
1
$156.746
5
$154.298
10
$133.054
13
$132.392
25
$125.403
38
$124.787
50 +
$121.293
