2TL1-1A

MICRO SWITCH™ Toggle Switches: TL Series, Double Pole Double Throw (DPDT) 3 Position (On - Off - On), Screw Terminals, Locking Lever (Locked In Three Positions), Military Part Number MS24659-21A ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

2TL1-1A Toggle Switch from Honeywell comes in a step-design case with environment-proof sealing and silver cadmium oxide contacts. It comes with a locking lever and ON OFF ON switch configuration. The Pull-to-Unlock levers of this switch helps prevent accidental operation. It’s 2 and 3 position function allows both maintained and momentary toggle action. This DPDT toggle switch is temperature-resistant and has high strength.

Toggle Switches are devices that are manually actuated by means of a projecting lever, such as a mechanical lever, handle or by a rocking mechanism. These electrical switches are available in many different styles and sizes. Honeywell Switch 2TL1-1A is often used in various applications such as industrial machinery, military and commercial aviation, construction equipment, test instruments, agricultural machinery, process control, and medical instrumentation.

Product Highlights:

  • Environment-proof sealing
  • Completely sealed switching chamber
  • 1, 2, and 4 pole circuitry
  • Standard and pull-to-unlock levers
  • Step-design case provides added space between terminals to help prevent shorting
  • 2 and 3 position, maintained and momentary toggle action
  • Silver cadmium oxide contacts
  • Temperature-resistant
  • Temperature range: -85 °F to 160 °F
  • Qualified to MIL-DTL-3950
  • UL recognized, CSA certified
  • CE approved

Potential Applications:

  • Industrial machinery and equipment
  • Military and commercial aviation
  • Construction equipment
  • Test instruments
  • Agricultural machinery
  • Process control
  • Medical instrumentation

Search Keywords: 2TL11A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
2TL1-1A
Alias/AKA:
MS24659-21A
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
US
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Pole Throw Configuration:
2P2T (DPDT)
Switch Configuration:
On Off On
Contact Rating @ Voltage:
745.7@(CSA/UL) A
Actuator Style:
Locking Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Screw
Dimension:
34.04 x 23.11 x 75.18 mm
Operating Temperature:
-65 to 71 °C

IN STOCK: 365

Ships today, if you order in

Factory Lead-Time 20 Weeks

Price (USD)

Qty
Unit Price
1
$88.89
5
$84.35
10
$80.22
20
$78.19
50
$77.20
100 +
$75.47
