2TL1-2G

The 2TL1-2G is a 2-pole, 2-position (ON-OFF) sealed toggle switch qualified for military and industrial applications. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 2TL1-2G is a 2-pole, 2-position (ON-OFF) toggle switch from the Honeywell TL Series, designed for high-reliability manual switching. This switch features environment-proof sealing and is qualified to MIL-S-3950 standards, with the military part number MS24524-22. It has maintained action in both positions and utilizes silver cadmium oxide contacts for robust performance. The switch is rated for 20 A resistive at 28 VDC and 15 A at 125 VAC, operating over a temperature range of -65°C to +71°C. Its durable and sealed construction makes it ideal for demanding applications in industrial machinery, military equipment, and aerospace.

Product Highlights:

  • Qualified to MIL-S-3950
  • Environment-proof sealing
  • 1,2, and 4 pole circuitry
  • Standard and pull-to-unlock levers
  • 2 and 3 position, maintained and momentary toggle action
  • Temperature range: -85 F to +160 F
  • Completely sealed switching chamber
  • Step-design case provides added space between terminals to help prevent shorting
  • UL recognized, CSA certified
  • CE approved

Potential Applications:

  • Industrial machinery and equipment
  • Military and commercial aviation
  • Construction equipment
  • Test instruments
  • Agricultural machinery
  • Process control
  • Medical instrumentation

Search Keywords: 2TL12G

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
2TL1-2G
Alias/AKA:
MS24659-22G
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
85365011
COO:
US
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Pole Throw Configuration:
2P1T (DPST)
Switch Configuration:
OFF None ON
Contact Rating @ Voltage:
745.7 A
Actuator Style:
Locking Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Screw
Dimension:
34.04 x 23.11 x 75.18 mm
Operating Temperature:
-65 to 71 °C

IN STOCK: 100

Ships today, if you order in

Factory Lead-Time 19 Weeks

Price (USD)

Qty
Unit Price
1
$96.31
5
$91.67
10
$83.48
20
$81.08
50
$72.79
100 +
$66.73
