2TL1-5K by honeywell
Image is representational - see mfr. specs

2TL1-5K

Honeywell

The 2TL1-5K is a 2-pole, 3-position, environmentally sealed toggle switch featuring a pull-to-unlock lever that is locked out of the center position. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 2TL1-5K is a 2-pole, 3-position toggle switch from the TL series, designed for manual control in demanding environments. It provides an (ON)-OFF-ON circuit configuration, where one ON position is momentary and the other is maintained. This switch is qualified to MIL-S-3950 and features environment-proof sealing for reliability. A key safety feature is its pull-to-unlock lever, which is locked out of the center OFF position to prevent accidental operation. It operates reliably across a temperature range of -65°C to +71°C, making it suitable for industrial machinery, military, and aerospace applications.

Product Highlights:

  • Qualified to MIL-S-3950
  • Environment-proof sealing
  • 1,2, and 4 pole circuitry
  • Standard and pull-to-unlock levers
  • 2 and 3 position, maintained and momentary toggle action
  • Temperature range: -85 F to +160 F
  • Completely sealed switching chamber
  • Step-design case provides added space between terminals to help prevent shorting
  • UL recognized, CSA certified
  • CE approved

Potential Applications:

  • Industrial machinery and equipment
  • Military and commercial aviation
  • Construction equipment
  • Test instruments
  • Agricultural machinery
  • Process control
  • Medical instrumentation

Search Keywords: 2TL15K

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
2TL1-5K
Alias/AKA:
MS24659-31K
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
85365000
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Pole Throw Configuration:
2P2T (DPDT)
Switch Configuration:
ON OFF (ON)
Contact Rating @ Voltage:
372.85 A
Actuator Style:
Locking Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Screw
Dimension:
33.5mm x 22.6mm x 72.9mm
Operating Temperature:
-65 to 71 °C

IN STOCK: 62

Can Ship immediately

MOQ for out of Stock Qty: 13

Factory Lead-Time 20 Weeks

Price (USD)

Qty
Unit Price
1
$84.84
5
$78.73
10
$77.97
13
$77.58
25
$67.36
38
$67.02
50 +
$65.68
