311SM4-T by honeywell

311SM4-T

Honeywell

MICRO SWITCH™ Subminiature Basic Switches: SM Series, Single Pole Double Throw (SPDT), 5 A at 250 Vac, Simulated Roller Actuator, Solder Termination ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

Snap action switches are highly sensitive switches that respond to very small movements and can rapidly change from one contact position to the other. This Roller Lever Switch is mostly used in timing devices, test instruments, vending machines, aerospace, medical and dental equipment, appliances, computer and business equipment, communications equipment and manually operated devices.

311SM4-T Snap Action Switch from Honeywell comes with a long operating life and an elongated mounting hole for easier, more accurate mounting. Featuring a choice of actuation, electrical termination and operating characteristics, this subminiature basic switch offers reliable functionality and is used for simple or precision application needs.

Product Highlights:

  • Optional series constructions available (gold contacts for low energy switching, bifurcated gold contacts for maximum reliability, power load switching capability to 11 A)
  • Choice of electrical termination (solder, quick connect, PCB)
  • Long operating life
  • Elongated mounting hole for easier, more accurate mounting
  • Choice of actuation (plunger, as well as a variety of integral and auxiliary actuators)
  • Choice of operating characteristics (sensitive differential travel as low as 0.0254 mm [0.001 in] maximum, low operating force to 0.56 N [2.0 oz.] maximum)

Potential Applications:

  • Aerospace
  • Instrumentation
  • Appliances
  • Vending machines
  • Timing devices
  • Office equipment
  • Computer/business equipment
  • Test instruments
  • Medical/dental equipment
  • Communications equipment
  • HVAC equipment
  • Manually operated devices
  • Valves

Search Keywords: 311SM4T

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
311SM4-T
RoHS:
Yes
HTS:
85365009
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Simulated Roller Lever
Contact Rating @ Voltage:
5 A
Maximum Movement Differential:
0.48 mm
Operating Force:
0.39 N
Termination Style:
Solder
Dimension:
24.05mm x 6.4mm x 14.5mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 1,413

Ships today, if you order in

Minimum Order: 10

Multiple: 10

Factory Lead-Time 17 Weeks

Price (CAD)

Qty
Unit Price
10
$14.241
30
$12.832
50
$12.296
100
$11.562
250
$11.439
500
$11.378
1,000 +
$11.317
Suppliers Standard Package
Log in for special pricing
Click for Quote
