311SX3-T by honeywell
Image is representational - see manufacturer specifications
Honeywell Authorized Distributor

311SX3-T

MICRO SWITCH™ Subminiature Basic Switches: SX Series, Single Pole Double Throw (SPDT), 5 A at 250 Vac, Straight Lever Actuator, Solder Termination ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

Snap action switches are highly sensitive switches that respond to very small movements and can rapidly change from one contact position to the other. The SX series subminiature basic micro switches are used for simple or precision on/off application needs. These highly sensitive switches are mostly used in aerospace, instrumentation, timing devices, vending machines, computer/business equipment, test instruments, HVAC equipment's, office equipment's, medical and dental equipment's, manually operated devices, and valves.

311SX3-T Snap Action Switch from Honeywell comes with a long operating life and an elongated mounting hole for easier, more accurate mounting.

Product Highlights:

  • Long operating life
  • Elongated mounting hole for easier, more accurate mounting
  • Long mechanical life up to 10,000,000 cycles
  • Ampere rating: 5 A
  • Choice of electrical termination (solder, quick connect, PCB)
  • Choice of actuation (plunger, as well as a variety of integral and auxiliary actuators)

Potential Applications:

  • Aerospace
  • Appliances
  • Vending machines
  • Timing devices
  • Office equipment
  • Computer/business equipment
  • Test instruments
  • Medical/dental equipment
  • Communications equipment
  • HVAC equipment
  • Manually operated devices
  • Valves

Search Keywords: 311SX3T

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
311SX3-T
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
85365000
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
10
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
N/A/Plastic/Straight Lever
Contact Rating @ Voltage:
5 A
Maximum Movement Differential:
1.52 mm
Operating Force:
0.2 N
Termination Style:
Solder
Dimension:
35.35mm x 5.1mm x 13.6mm
Body Orientation:
Straight
IP Rating:
N/A
