3MN1 by honeywell

3MN1

Honeywell

MICRO SWITCH™ Basic Switches: MN Series, Double Pole Double Throw (DPDT), 15 A at 480 Vac, Pin Plunger Actuator, 3,34 N - 5,56 N [12 - 20 oz] Operating Force, Screw Termination ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

Snap action switches are short contact sensitive switches with the ability to respond quickly to small movements. This plunger switch is mostly used in industrial equipment's, presses and machine tools for its long mechanical life.

3MN11 Snap Action Switch from Honeywell is designed with arc-resistant plastic. The motor handling capacity of this Honeywell switch is 746 W [1 hp] at 240 Vac. The double-break circuitry and the space between the terminals reduces possibility of any short circuiting in the machine tools or industrial equipment's they are used in.

Product Highlights:

  • Arc-resistant plastic
  • Double-break circuitry
  • Power load switching capability to 15 A at 600 Vac
  • Long mechanical life to 10,000,000 cycles at 95% survival
  • Space between terminals reduces possibility of shorting
  • Motor handling capacity of 746 W [1 hp] at 240 Vac

Potential Applications:

  • Machine Tools
  • Presses
  • Industrial equipment

Search Keywords: 3MN1

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
3MN1
RoHS:
Yes
HTS:
85365009
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Mounting:
Through Hole
Pole Throw Configuration:
DPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Plastic/Pin Plunger
Contact Rating @ Voltage:
745.7@UL A
Maximum Movement Differential:
0.64 mm
Operating Force:
5.56 N
Termination Style:
Screw
Dimension:
63.5 x 17.15 x 34.16 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 0

On Order: 496   can ship 12/11/25

MOQ for out of Stock Qty: 50

Factory Lead-Time 29 Weeks

Price (CAD)

Qty
Unit Price
1
$146.592
10
$129.181
25
$127.236
50
$124.786
100
$124.174
150
$123.545
200 +
$122.932
Suppliers Standard Package
Log in for special pricing
Click for Quote
