91SS12-2 by honeywell

91SS12-2

Honeywell

Honeywell Hall-effect Linear Position Sensor: 91SS Series,Ratiometric Linear Hall-effect Position Sensor IC, Rationmetric sourcing output, 3-pin, Through-hole ceramic substrate, 7.5 mV/G at 12 Vdc supply voltage ...

Datasheet
RoHS Compliant
Box Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The HONEYWELL part 91SS12-2 is a high-quality Hall-effect linear position sensor designed for precise and accurate position sensing applications. This sensor belongs to the 91SS series and utilizes a ratiometric linear Hall-effect position sensor IC.Featuring a ratiometric sourcing output, this sensor ensures reliable and consistent performance. The 3-pin configuration allows for effortless integration and easy installation. The through-hole ceramic substrate adds to the sensor's robustness and durability.Operating at a supply voltage of 12 Vdc, the 91SS12-2 provides a sensitivity of 7.5 mV/G, making it ideal for applications that require precise position detection. Whether it's in industrial machinery, automotive systems, or robotics, this Honeywell sensor delivers accurate and dependable performance every time.

Product Highlights:

  • Single current sinking or current sourcing output
  • Standard mounting centers
  • Laser trimmed thin film and thick film resistors minimize sensitivity variations and compensate for temperature variations

Potential Applications:

  • Ignition timing
  • Power sensing
  • Valve position
  • Robotics control
  • Current sensing
  • Linear or rotary motion detection
  • Length measurement
  • Flow sensing
  • RPM sensing
  • Security systems

Search Keywords: 91SS122

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
91SS12-2
RoHS:
Yes
HTS:
85437000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
250
Package Type:
Box
Magnetic Type:
Linear
Maximum Output Current:
10 mA
Mounting:
PCB Through Hole
Minimum Magnetic Sensor Release Point:
N/A
Maximum Magnetic Sensor Operating Point:
N/A
Output Type:
3 to 9 V
Output Driver:
Open Collector
Product Type:
Analog
Dimension:
7.62 x 1.78 x 15.24 mm
Typical Operating Supply Voltage:
12 V
Termination Type:
PC Pins
Operating Temperature:
-40 to 150 °C

IN STOCK: 582

Ships today, if you order in

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
1
$157.374
3
$149.505
5
$142.027
10 +
$134.930
Log in for special pricing
Click for Quote
