91SX39-T by honeywell

91SX39-T

Honeywell

MICRO SWITCH™ Subminiature Basic Switches: SX Series, Single Pole Double Throw (SPDT), 7 A at 28 Vdc, Pin Plunger Actuator, Solder Termination ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The HONEYWELL part 91SX39-T is a MICRO SWITCH Subminiature Basic Switch from the SX Series. It features a Single Pole Double Throw (SPDT) configuration with a 7 A rating at 28 Vdc. The switch is equipped with a pin plunger actuator and solder termination for easy installation. Ideal for a wide range of applications requiring a reliable and durable switch solution.

Product Highlights:

  • Long operating life
  • Elongated mounting hole for easier, more accurate mounting
  • Choice of actuation (plunger, as well as a variety of integral and auxiliary actuators)
  • Choice of electrical termination (solder, quick connect, PCB)
  • Choice of operating characteristics
  • Optional series constructions available (gold contacts for low energy switching, bifurcated gold contacts for maximum reliability, power load switching capability to 7 A)
  • MIL-PFR-8805 qualified listings available

Potential Applications:

  • Aerospace
  • Appliances
  • Vending machines
  • Timing devices
  • Office equipment
  • Computer/business equipment
  • Test instruments
  • Medical/dental equipment
  • Communications equipment
  • HVAC equipment
  • Manually operated devices
  • Valves

Search Keywords: 91SX39T

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
91SX39-T
RoHS:
Yes
HTS:
85365080
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Plastic/Pin Plunger
Contact Rating @ Voltage:
7@115VAC 28VDC A
Maximum Movement Differential:
0.13 mm
Operating Force:
1.39 N
Termination Style:
Solder
Dimension:
12.7 x 3.96 x 13.21 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 699

Ships today, if you order in

Factory Lead-Time 4 Weeks

Price (CAD)

Qty
Unit Price
1
$41.790
5
$34.914
25
$33.628
50
$29.523
100
$29.080
250
$28.927
500 +
$28.620
Suppliers Standard Package
