AML22CBL2AD by honeywell

AML22CBL2AD

Honeywell

BODY ONLY - Switch - PB - Pnl Mnt - SQ - DPDT - Alt - Silver - Yellow LED - 15 Vdc - QC/Solder ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

This HONEYWELL part AML22CBL2AD is a versatile and durable body-only switch designed for panel mounting. Featuring a square shape and a double-pole double-throw configuration, it offers alternate functionality with a sleek silver design and a vibrant yellow LED indicator. Operating at 15 Vdc, this switch can be easily connected via quick connect or soldering methods.

Product Highlights:

  • Identical to AML21 switches, except furnished with high efficiency LED display.
  • Rectangular LED s are flush with button surface, providing wide angle indication.
  • Optional diode protection for LED s.
  • 5 thru 24 Vdc LED devices have an internal resistor to maintain current at nominal 20 mA.
  • UL recognized, CSA certified.
  • LED circuit independent of switch circuit.

Search Keywords: AML22CBL2AD

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
AML22CBL2AD
RoHS:
Yes
HTS:
8536509033
COO:
US
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Mounting:
Panel Mount
Pole Throw Configuration:
DPDT
Bushing Type:
N/R
Switch Configuration:
N.O./N.C.
Contact Rating @ Voltage:
N/A
Actuator Style:
Square Button
Illumination:
Yellow,LED
Terminal Type:
Quick Connect/Solder
Body Orientation:
Straight
Dimension:
N/A

IN STOCK: 103

Can Ship immediately

MOQ for out of Stock Qty: 25

Factory Lead-Time 30 Weeks

Price (CAD)

Qty
Unit Price
1
$211.641
5
$176.373
10
$167.261
25
$161.980
50
$161.164
75
$160.363
100 +
$159.563
Suppliers Standard Package
Log in for special pricing
Click for Quote
