BA-2RV-A2 by honeywell

BA-2RV-A2

Honeywell

MICRO SWITCH™ Basic Switches: BA Series, Single Pole Double Throw (SPDT), 20 A at 250 Vac, Straight Lever Actuator, 0,72 N [2.5 oz] Operating Force, Silver Contacts, Screw Termination ...

Datasheet
RoHS Compliant
Box Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

Snap Action Switches are electromechanical devices that are used to open or close an electrical circuit at a rapid speed. They are generally used in timing devices, irrigation systems, semi-trailer trucks, office equipment, test instruments, HVAC equipment, manually operated devices, and valves.

BA-2RV-A2 Snap Action Switch from Honeywell is a standard basic switch, designed for precision on or off applications. This SPDT Lever Switch delivers long mechanical life of up to 20,000,000 cycles at 95% survival rate. It also provides a range of actuation, termination and operating characteristics for design flexibility and high-performance. The current rating of this Honeywell Switch ranges from 15 A to 25 A.

Product Highlights:

  • Accepted world-wide standard "Large Basic" switch
  • Low operating force and differential travel
  • Long mechanical life up to 20,000,000 cycles at 95% survival
  • Elongated mounting hole for easier, more accurate mounting
  • Current rating ranges from 15 A to 25 A
  • Choice of actuation, termination and operating characteristics

Search Keywords: BA2RVA2

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
BA-2RV-A2
RoHS:
Yes
HTS:
85365009
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Package Type:
Box
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Lever
Contact Rating @ Voltage:
1491.4 A
Maximum Movement Differential:
2.77 mm
Operating Force:
0.7 N
Termination Style:
Screw
Dimension:
76.28mm x 17.45mm x 44.07 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 2

Ships today, if you order in

Factory Lead-Time 12 Weeks

Price (CAD)

Qty
Unit Price
1
$39.017
10
$25.879
25
$24.562
50
$23.184
200
$22.602
400
$22.296
600 +
$22.112
