BZ-2RS-A2 by honeywell

BZ-2RS-A2

Honeywell

MICRO SWITCH™ Premium Large Basic Switches: BZ Series, Single Pole Double Throw (SPDT), 15 A 125/250 Vac, ENEC 16 A 250 Vac, 5 mm [0.20 in] Diameter Hardened Steel Additional Overtravel Plunger, Binding Head Combination Screw Termination with Cup Washers, Mounting Holes will Accept Pins or Screws, UL, CE, CSA, ENEC ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

A Snap Action Switch is a type of momentary contact micro switch which operates at rapid speed as it takes very little force or stimulus to operate. These highly sensitive switches are very often used in test instruments, medical/dental equipment. This Snap Action Limit Switch is also used in HVAC equipment, manually operated devices and valves.

BZ-2RS-A2 Snap Action Switch from Honeywell is a standard basic switch that comes with low operating force and differential travel, elongated mounting hole for easier, more accurate mounting and choice of actuation, termination and operating characteristics.

Product Highlights:

  • This Honeywell Snap Action Switch has a long mechanical life up to 20,000,000 cycles at 95% survival
  • Elongated mounting hole for easier, more accurate mounting
  • Current rating ranges from 15 A to 25 A
  • Accepted world-wide standard "Large Basic" switch
  • Low operating force and differential travel
  • Choice of actuation, termination and operating characteristics

Potential Applications:

  • Irrigation systems
  • Semi-trailer trucks
  • Timing devices
  • Office equipment
  • Test instruments
  • Medical/dental equipment
  • HVAC equipment
  • Manually operated devices
  • Valves

Search Keywords: BZ2RSA2

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
BZ-2RS-A2
RoHS:
Yes
HTS:
85365080
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Steel/Overtravel Plunger
Contact Rating @ Voltage:
15 A
Maximum Movement Differential:
0.063 mm
Operating Force:
3.61 N
Termination Style:
Screw
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 364

Can Ship immediately

Factory Lead-Time 14 Weeks

Price (CAD)

Qty
Unit Price
1
$40.579
10
$27.624
25
$26.722
50
$25.818
200
$25.052
400
$24.929
600 +
$24.807
