BZ-2RW80 by honeywell

BZ-2RW80

Honeywell

MICRO SWITCH™ Premium Large Basic Switches: BZ Series, Single Pole Double Throw (SPDT), 15 A 125/250 Vac, ENEC 16 A 250 Vac, 63,5 mm [2.50 in] Straight Lever Actuator, Solder Termination, Mounting Holes will Accept Pins or Screws, UL, CE, CSA, ENEC ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

A Snap Action Switch is a type of momentary contact micro switch which operates at a rapid speed as it takes very little force or stimulus to operate. This SPDT Micro Switch is widely used in irrigation systems, semi-trailer trucks, office equipment, medical and dental equipment, HVAC equipment, and manually operated devices.

BZ-2RW80 Snap Action Switch from Honeywell comes with low operating force and differential travel to deliver reliable functionality. Featuring a choice of actuation, termination and operating characteristics, this Honeywell switch is ideal for a variety of industrial and mechanical applications. The elongated mounting hole in this snap action switch enables easier and more accurate mounting. This standard basic switch has a long mechanical life of up to 20,000,000 cycles at a 95% survival rate.

Product Highlights:

  • Long mechanical life up to 20,000,000 cycles at 95% survival
  • Elongated mounting hole for easier, more accurate mounting
  • Current rating ranges from 15 A to 25 A
  • Choice of actuation, termination and operating characteristics
  • Accepted world-wide standard "Large Basic" switch
  • Low operating force and differential travel

Search Keywords: BZ2RW80

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
BZ-2RW80
RoHS:
Yes
HTS:
8536509065
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Straight Lever
Contact Rating @ Voltage:
186.42 A
Maximum Movement Differential:
1.27 mm
Operating Force:
0.7 N
Termination Style:
Solder
Dimension:
74.78 x 17.45 x 33.73 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 235

Ships today, if you order in

Factory Lead-Time 18 Weeks

Price (CAD)

Qty
Unit Price
1
$34.668
10
$28.451
25
$26.752
50
$25.604
100
$25.038
250
$24.868
500 +
$24.746
