BZ-2RW80196-A2 by honeywell

BZ-2RW80196-A2

Honeywell

MICRO SWITCH™ Premium Large Basic Switches: BZ Series, Single Pole Double Throw (SPDT), 15 A 125/250 Vac, ENEC 16 A 250 Vac, 48,3 mm [1.90 in] Simulated Roller Lever Actuator, Binding Head Combination Screw Termination with Cup Washers, Mounting Holes will Accept Pins or Screws, UL, CE, CSA, ENEC ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

BZ-2RW80196-A2 Snap Action Switch from Honeywell comes with a low operating force and has a current rating of 15 A. Elongated mounting hole of this switch provides easier and accurate mounting. It also comes with screw termination, simulated roller lever actuator and silver contacts. This lever switch has a long mechanical life up to 20,000,000 cycles at 95% survival.

Snap Action Switches are devices that are used to open or close an electrical circuit at a rapid speed. They are also known as micro switches. Honeywell Snap Action Switch BZ-2RW80196-A2 is widely used in various applications such as irrigation systems, semi-trailer trucks, timing devices, office equipment, test instruments, medical or dental equipment, HVAC equipment, manually operated devices, and valves.

Product Highlights:

  • Accepted world-wide standard "Large Basic" switch
  • Low operating force and differential travel
  • Elongated mounting hole for easier and accurate mounting
  • Simulated roller lever actuator
  • Current rating ranges from 15 A to 25 A
  • Long mechanical life up to 20,000,000 cycles at 95% survival
  • Choice of actuation, termination and operating characteristics
  • Operating temperature range: -55 °C to 85 °C

Search Keywords: BZ2RW80196A2

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
BZ-2RW80196-A2
RoHS:
Yes
HTS:
8536509901
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Simulated Roller Lever
Contact Rating @ Voltage:
186.42 A
Maximum Movement Differential:
1.02 mm
Operating Force:
0.97 N
Termination Style:
Screw
Dimension:
59.54mm x 17.45mm x 44.86 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 330

Ships today, if you order in

Factory Lead-Time 12 Weeks

Price (CAD)

Qty
Unit Price
1
$60.058
5
$51.850
25
$47.961
50
$40.733
100
$31.775
250
$31.622
500 +
$31.453
