BZE6-RN80X2 by honeywell
Image is representational - see manufacturer specifications
Honeywell Authorized Distributor

BZE6-RN80X2

MICRO SWITCH™ Medium-Duty Limit Switches: BZ Series Enclosed Basic Switch, Side Mount, Die-Cast Zinc, 1NC 1NO Single Pole Double Throw (SPDT), Snap Action, Roller Plunger Actuator with Seal Boot, Maintained Contact with Reset Plunger, 0.5 in - 14NPT Conduit ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The HONEYWELL BZE6-RN80X2 is a MICRO SWITCHâ„¢ medium-duty limit switch from the BZ series. Designed for reliable and durable performance, this enclosed basic switch features a side mount configuration and is made of rugged die-cast zinc. Equipped with 1 normally closed (NC) and 1 normally open (NO) single pole double throw (SPDT) contacts, this switch offers versatility in a variety of applications. The snap-action mechanism ensures quick and precise switching, with a roller plunger actuator for smooth and efficient actuation. The switch also includes a seal boot for added protection against dust, dirt, and moisture.Featuring a maintained contact with reset plunger, this limit switch allows for easy reset and consistent operation. The 0.5 in - 14NPT conduit enables simple and secure installation.The HONEYWELL BZE6-RN80X2 is a reliable and versatile limit switch that is ideal for medium-duty applications requiring precise and efficient operation.

Product Highlights:

  • Side or flange mount
  • Momentary or maintained contact
  • Grounding screw
  • High capacity (22 amp) available
  • Temperature range -32 C to +71 C [ -25 F to +160 F]
  • Zinc Die-Cast housing NEMA 1
  • UL Recognized, file #E12252
  • CSA Certified, file #LR41372
  • NEMA 1, 3, 4 /IP66
  • Pre-leaded or connector termination options

Potential Applications:

  • Packaging equipment
  • Special machinery
  • Textile machinery
  • Conveyors
  • Construction machinery and equipment
  • Printing trades machinery
  • Overhead cranes and hoists

Search Keywords: BZE6RN80X2

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
BZE6-RN80X2
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
85365080
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
10
Type:
Enclosed
Actuator Style:
Top Roller Plunger
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Operating Force:
15.57 N
Maximum Current Rating:
0.5@125VDC A
Terminal Type:
Conduit
NEMA Standard as Enclosure Rating:
1, 3, 4
Body Orientation:
Straight
