BZE6-RNX1 by honeywell

BZE6-RNX1

Honeywell

Switch Limit N.O./N.C. SPDT Top Plunger Conduit 0.5A 250VDC 1/2HP 5.56N Linear Screw Mount ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The HONEYWELL part BZE6-RNX1 is a versatile and reliable switch limit, designed to operate under demanding conditions. It offers a dual action mechanism with both normally open and normally closed options, providing enhanced flexibility for different applications. With a rating of 0.5A at 250VDC and 1/2HP, this switch is capable of handling high voltage and power requirements. The top plunger design ensures precise and accurate activation/deactivation, while the included conduit offers convenient mounting options. Built with rugged materials and a linear screw mount, the BZE6-RNX1 delivers long-lasting performance in even the most challenging environments. Trust HONEYWELL for top-quality and dependable limit switches that meet your needs.

Product Highlights:

  • Side or flange mount
  • Momentary or maintained contact
  • Grounding screw
  • High capacity (22 amp) available
  • Temperature range -32 C to +71 C [ -25 F to +160 F]
  • Zinc Die-Cast housing NEMA 1
  • UL Recognized, file #E12252
  • CSA Certified, file #LR41372
  • NEMA 1, 3, 4 /IP66
  • Pre-leaded or connector termination options

Potential Applications:

  • Packaging equipment
  • Special machinery
  • Textile machinery
  • Conveyors
  • Construction machinery and equipment
  • Printing trades machinery
  • Overhead cranes and hoists

Search Keywords: BZE6RNX1

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
BZE6-RNX1
RoHS:
Yes
HTS:
85365090
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Type:
Medium Duty
Actuator Style:
Top Plunger
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Operating Force:
5.56 N
Maximum Current Rating:
0.5@125VDC A
Terminal Type:
Conduit
NEMA Standard as Enclosure Rating:
1, 3, 4
Body Orientation:
Straight

IN STOCK: 157

Can Ship immediately

On Order: 130   can ship 1/9/26

Factory Lead-Time 31 Weeks

Price (CAD)

Qty
Unit Price
1
$322.813
3
$318.066
5
$316.474
10 +
$265.328
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Product Changes
