BZ-R21-A2 by honeywell

BZ-R21-A2

Honeywell

MICRO SWITCH™ Premium Large Basic Switches: BZ Series, Single Pole Double Throw (SPDT), 10 A 125/250 Vac, Pin Plunger, Binding Head Combination Screw Termination with Cup Washers, Mounting Holes will Accept Pins or Screws, UL, CSA ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

BZ-R21-A2 Snap Action Switch from Honeywell comes with a pin plunger actuator, solder termination and silver contacts. It features an elongated mounting hole for easier and accurate mounting. It also comes with a wide choice of actuation, termination and operating characteristics. This snap switch has a low operating force and a long mechanical life up to 20,000,000 cycle at 95% survival.

Snap Action Switches are devices that are used to open or close an electrical circuit at a rapid speed. They are highly sensitive and are also known as micro switches. Honeywell Snap Action Switch BZ-R21-A2 has a current rating of 10 A and is widely used in various applications such as irrigation systems, semi-trailer trucks, timing devices, office equipment, test instruments, medical or dental equipment, HVAC equipment, manually operated devices, and valves.

Product Highlights:

  • Accepted world-wide standard "Large Basic" switch
  • Low operating force and differential travel
  • Elongated mounting hole for easier and accurate mounting
  • Pin plunger actuator
  • Long mechanical life up to 20,000,000 cycles at 95% survival
  • Choice of actuation, termination and operating characteristics
  • Operating temperature range: -55 °C to 85 °C
  • Agency approvals and standards from UL, CSA, ENEC

Potential Applications:

  • Irrigation systems
  • Semi-trailer trucks
  • Timing devices
  • Office equipment
  • Test instruments
  • Medical/dental equipment
  • HVAC equipment
  • Manually operated devices
  • Valves

Search Keywords: BZR21A2

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
BZ-R21-A2
RoHS:
Yes
HTS:
85365000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Stainless Steel/Pin Plunger
Contact Rating @ Voltage:
10 A
Maximum Movement Differential:
0.013 mm
Operating Force:
1.11 N
Termination Style:
Screw
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 1,200

Ships today, if you order in

Factory Lead-Time 11 Weeks

Price (CAD)

Qty
Unit Price
1
$46.459
10
$34.561
25
$33.811
50
$33.643
100
$33.475
250
$32.081
500 +
$31.912
