LSA5A by honeywell

LSA5A

Honeywell

MICRO SWITCH™ Heavy-Duty Limit Switches: HDLS Series, Epoxy-Coated Zinc Housing, Side Rotary, Momentary, No Lever, 120 V Neon Indicator, 1NC 1NO Single Pole Double Throw (SPDT) Snap Action, Double Break, AC 15, A600; DC 13, R300, 0.5 in - 14 NPT Conduit, Plug-In, Operating Temperature: -12 °C to 121 °C [10 °F to 250 °F], IP 65/66/67, NEMA 1, 3, 4, 4X, 6, 6P, 12, and 13, Agency Approvals: UL, CSA, CE, CCC ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

A limit switch is an electromechanical switch device which is used as part of a control system in a wide variety of applications. Limit switches act as a contact device that makes or breaks an electrical connection. This Honeywell switch is widely used in welding, packaging, machine tools, presses, pulp and paper, PLC Interface, and material handling.

LSA5A Limit Switch from Honeywell is a heavy-duty limit switch with unique all-metal drive train to deliver consistent operation even at high temperatures. This Honeywell limit switch features a wide variety of operating heads and field adjustable operating modes for reduced inventory. This micro switch is available in low temperature versions to -40 °C (-40 °F), explosion-proof versions, and completely fluorocarbon (FC) sealed versions.

Product Highlights:

  • Pre-leaded cable or pre-wired connector types
  • Epoxy filled wash down (NEMA 6P) types
  • Captive head and body screws
  • Designed to withstand seismic shock
  • Completely fluorocarbon (FC) sealed versions
  • Complete choice of circuitry and electrical rating options
  • Explosion-proof versions
  • Low temperature versions to -40°C (-40°F)
  • Stainless steel (NEMA 4X) versions
  • Wide variety of operating heads
  • Field adjustable operating modes, for reduced inventory
  • Plug-in and non plug-in versions have identical operating characteristics and are dimensionally interchangeable
  • Manifold (rear-wire) version
  • Convenience of on-the-spot adjustment instructions

Potential Applications:

  • Machine Tools
  • Material Handling
  • Packaging
  • Presses
  • Pulp and Paper
  • Welding
  • PLC Interface

Search Keywords: LSA5A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
LSA5A
RoHS:
Yes
HTS:
85365009
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Type:
Heavy Duty
Actuator Style:
Side Rotary
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Operating Force:
N/A
Dimension:
41.1 x 62 x 106.7 mm
Maximum Current Rating:
10@24VDC A
Terminal Type:
Conduit
NEMA Standard as Enclosure Rating:
1, 3, 4, 4X, 6, 6P, 12, 13
Body Orientation:
Right Angle

IN STOCK: 31

Ships today, if you order in

Factory Lead-Time 5 Weeks

Price (USD)

Qty
Unit Price
1
$309.628
3
$305.065
5
$302.048
10 +
$280.263
