LSF1A by honeywell

LSF1A

Honeywell

MICRO SWITCH™ Heavy-Duty Limit Switches: HDLS Series, Epoxy-Coated Zinc Housing, Momentary, Side Roller Plunger, Ø 12,7 mm x 4,8 mm [0.50 in x 0.19 in] Steel Roller, 1NC 1NO Single Pole Double Throw (SPDT) Snap Action, Double Break, AC 15, A600; DC 13, R300, 0.5 in - 14 NPT Conduit, Plug-In, Operating Temperature: -12 °C to 93 °C [10 °F to 200 °F], IP 65/66/67, NEMA 1, 3, 4, 4X, 6, 6P, 12, and 13, Agency Approvals: UL, CSA, CE, CCC ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The HONEYWELL part LSF1A is a MICRO SWITCH„¢ Heavy-Duty Limit Switch from the HDLS Series. It features an epoxy-coated zinc housing and a momentary, side roller plunger. The switch has a steel roller measuring 12.7 mm x 4.8 mm [0.50 in x 0.19 in]. This particular model has a 1NC 1NO single pole double throw (SPDT) snap action with a double break. It is suitable for use in AC 15, A600; DC 13, R300 applications. The limit switch has a 0.5 in - 14 NPT conduit and is plug-in style. It has an operating temperature range of -12 °C to 93 °C [10 °F to 200 °F] and is rated IP 65/66/67. It is also compliant with NEMA 1, 3, 4, 4X, 6, 6P, 12, and 13 standards. The HONEYWELL part LSF1A has been approved by several agencies including UL, CSA, CE, and CCC.

Product Highlights:

  • Wide variety of operating heads
  • Field adjustable operating modes, for reduced inventory
  • Convenience of on-the-spot adjustment instructions
  • Complete choice of circuitry and electrical rating options
  • Plug-in and non plug-in versions have identical operating characteristics and are dimensionally interchangeable
  • Manifold (rear-wire) version
  • Explosion-proof versions
  • Low temperature versions to -40 C (-40 F)
  • Captive head and body screws
  • Designed to withstand seismic shock
  • Stainless steel (NEMA 4X) versions
  • Pre-leaded cable or pre-wired connector types
  • Epoxy filled wash down (NEMA 6P) types
  • Completely fluorocarbon (FC) sealed versions

Potential Applications:

  • Machine Tools
  • Material Handling
  • Packaging
  • Presses
  • Pulp and Paper
  • Welding
  • PLC Interface

Search Keywords: LSF1A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
LSF1A
RoHS:
Yes
HTS:
85365009
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Type:
Heavy Duty
Actuator Style:
Side Roller Plunger
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Operating Force:
26.7 N
Dimension:
41.1 x 65.8 x 101.9 mm
Maximum Current Rating:
10@24VDC A
Terminal Type:
Conduit
NEMA Standard as Enclosure Rating:
1, 3, 4, 4X, 6, 6P, 12, 13
Body Orientation:
Right Angle

IN STOCK: 51

Ships today, if you order in

Factory Lead-Time 6 Weeks

Price (CAD)

Qty
Unit Price
1
$465.501
3
$445.455
5
$435.670
10 +
$432.960
