LSYAB2B by honeywell

LSYAB2B

Honeywell

MICRO SWITCH™ Heavy-Duty Limit Switches: HDLS Series, Epoxy-Coated Zinc Housing, Side Rotary, Momentary, No Lever, Low Temperature Fluorosilicone Sealed, 2NC 2NO Double Pole Double Throw (DPDT) Snap Action, Double Break, AC 15, A600; DC 13, R300, 0.75 in - 14 NPT Conduit, Plug-In, Operating Temperature: -40 °C to 121 °C [-40 °F to 250 °F], IP 65/66/67, NEMA 1, 3, 4, 4X, 6, 6P, 12, and 13, Agency Approvals: UL, CSA, CE, CCC ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The HONEYWELL part LSYAB2B is a heavy-duty limit switch from the MICRO SWITCH„¢ HDLS Series. It is designed with an epoxy-coated zinc housing and features a side rotary configuration. This particular model is momentary and does not include a lever. It is equipped with a low temperature fluorosilicone seal for enhanced protection. The switch has a double pole double throw (DPDT) snap action, with 2 normally closed (NC) and 2 normally open (NO) contacts. It also has double break capabilities and is rated for AC 15 and DC 13 applications, with a R300 rating. The LSYAB2B is designed with a 0.75 in - 14 NPT conduit for easy installation. It is a plug-in type of switch and has an impressive operating temperature range of -40 °C to 121 °C (-40 °F to 250 °F). It is IP 65/66/67 rated for dust and water protection, and it meets NEMA 1, 3, 4, 4X, 6, 6P, 12, and 13 standards. Furthermore, this switch has received several agency approvals including UL, CSA, CE, and CCC certifications. It is a reliable and durable option for various industrial applications.

Product Highlights:

  • Wide variety of operating heads
  • Field adjustable operating modes, for reduced inventory
  • Convenience of on-the-spot adjustment instructions
  • Complete choice of circuitry and electrical rating options
  • Plug-in and non plug-in versions have identical operating characteristics and are dimensionally interchangeable
  • Manifold (rear-wire) version
  • Explosion-proof versions
  • Low temperature versions to -40 C (-40 F)
  • Captive head and body screws
  • Designed to withstand seismic shock
  • Stainless steel (NEMA 4X) versions
  • Pre-leaded cable or pre-wired connector types
  • Epoxy filled wash down (NEMA 6P) types
  • Completely fluorocarbon (FC) sealed versions

Potential Applications:

  • Machine Tools
  • Material Handling
  • Packaging
  • Presses
  • Pulp and Paper
  • Welding
  • PLC Interface

Search Keywords: LSYAB2B

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
LSYAB2B
RoHS:
Yes
HTS:
8536500000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Type:
Heavy Duty
Actuator Style:
Side Rotary
Pole Throw Configuration:
DPDT
Switch Configuration:
N.O./N.C.
Operating Force:
N/A
Dimension:
47.8 x 62 x 119 mm
Maximum Current Rating:
10@24VDC A
Terminal Type:
Conduit
NEMA Standard as Enclosure Rating:
1, 3, 4, 4X, 6, 6P, 12, 13
Body Orientation:
Right Angle

IN STOCK: 3

Can Ship immediately

On Order: 20   can ship 12/22/25

Factory Lead-Time 4 Weeks
