MS24524-21 by honeywell

MS24524-21

Honeywell

Switch Toggle ON OFF ON DPDT Round Lever Screw 20A 277VAC 250VDC 745.7VA Panel Mount with Threads ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The Honeywell MS24524-21 is a high-quality electrical switch with a round lever, designed with a double-pole, double-throw (DPDT) configuration. This versatile switch is specifically intended for panel mount applications, featuring a secure screw connection. With a current rating of 20A for 277VAC, 250VDC, and a power rating of 745.7VA, it can handle a wide range of electrical loads. The threaded design ensures a secure and stable installation, while the ON-OFF-ON functionality allows for multiple circuit control options. Trust Honeywell for reliable and durable switches, perfect for a variety of industrial and commercial applications.

Product Highlights:

  • Qualified to MIL-S-3950
  • Environment-proof sealing
  • 1,2, and 4 pole circuitry
  • Standard and pull-to-unlock levers
  • 2 and 3 position, maintained and momentary toggle action
  • Temperature range: -85 F to +160 F
  • Completely sealed switching chamber
  • Step-design case provides added space between terminals to help prevent shorting
  • UL recognized, CSA certified
  • CE approved

Potential Applications:

  • Industrial machinery and equipment
  • Military and commercial aviation
  • Construction equipment
  • Test instruments
  • Agricultural machinery
  • Process control
  • Medical instrumentation

Search Keywords: MS2452421

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
MS24524-21
RoHS:
Yes
HTS:
85365090
COO:
US
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Pole Throw Configuration:
2P2T (DPDT)
Switch Configuration:
On Off On
Contact Rating @ Voltage:
745.7 A
Actuator Style:
Round Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Screw
Dimension:
33.5mm x 22.6mm x 63.47mm
Operating Temperature:
-65 to 71 °C

IN STOCK: 0

On Order: 483   can ship 12/11/25

Factory Lead-Time 41 Weeks

Price (USD)

Qty
Unit Price
1
$48.946
5
$42.941
10
$38.883
25
$38.295
50
$37.904
100
$36.617
250 +
$36.431
