MS24660-21A by honeywell

MS24660-21A

Honeywell

Switch Toggle ON OFF ON 4PDT Locking Lever Screw 20A 277VAC 250VDC 745.7VA Panel Mount with Threads ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 4TL1-1A Honeywell Toggle Switch features environment-proof sealing and temperature resistant characteristics. This 1, 2 and 4PDT Safety Toggle Switch comes with a step-design case which offers an extra space between the terminals to prevent short circuit. Toggle Switches are manually actuated by means of a projecting lever, such as mechanical lever, handle or a rocking mechanism.

The 4TL1-1A Honeywell switch allows both maintained and momentary toggle action. TL series toggle switches are temperature-resistant and have high strength and pull-to-unlock toggle levers. These electrical switches are available in many different styles and sizes. They are generally used in various applications such as industrial machinery and equipment, military and commercial aviation, construction equipment, agricultural machinery, and medical instrumentation.

Product Highlights:

  • Environment-proof sealing
  • Completely sealed switching chamber
  • 1, 2, and 4 pole circuitry
  • Standard and pull-to-unlock levers
  • Step-design case provides added space between terminals to help prevent shorting
  • 2 and 3 position, maintained and momentary toggle action
  • Temperature range: -85 °F to +160 °F
  • Qualified to MIL-DTL-3950
  • UL recognized, CSA certified
  • CE approved

Potential Applications:

  • Industrial machinery and equipment
  • Military and commercial aviation
  • Construction equipment
  • Test instruments
  • Agricultural machinery
  • Process control
  • Medical instrumentation

Search Keywords: MS2466021A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
MS24660-21A
RoHS:
Yes
HTS:
8536500000
COO:
US
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Pole Throw Configuration:
4P2T (4PDT)
Switch Configuration:
On Off On
Contact Rating @ Voltage:
745.7@(CSA/UL) A
Actuator Style:
Locking Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Screw
Dimension:
33.53 x 41.66 x 75.18 mm
Operating Temperature:
-65 to 72 °C

IN STOCK: 248

Can Ship immediately

Factory Lead-Time 22 Weeks

Price (CAD)

Qty
Unit Price
1
$186.651
5
$181.000
10
$160.419
15
$158.827
25
$150.435
50 +
$147.832
Log in for special pricing
Click for Quote
