NGCPA00NX01A1A by honeywell
Image is representational - see mfr. specs

NGCPA00NX01A1A

Honeywell

A compact, medium-duty limit switch in a plastic housing, featuring a side rotary actuator, 1NC/1NO silver contacts, and an M12 4-pin connector. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The NGCPA00NX01A1A is a compact, medium-duty limit switch from the Honeywell NGC Series. This model is configured with a durable plastic housing, a side rotary actuator with a standard fixed-length lever, and an 18 mm nylon roller. It features SPDT circuitry with 1NC/1NO snap-action silver contacts and terminates to an integrated M12 4-pin connector. The switch is sealed to IP67 and NEMA 1, 4, 12, 13 standards, ensuring reliable performance across an operating temperature range of -25 °C to 75 °C. Its robust design makes it suitable for various industrial applications such as boom position detection, machine tools, and packaging equipment.

Search Keywords: NGCPA00NX01A1A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
NGCPA00NX01A1A
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509055
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Type:
Compact
Actuator Style:
Side Rotary with Roller Lever
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Operating Force:
N/A
Dimension:
45 x 36 x 106.3 mm
Maximum Current Rating:
6@120VAC A
Terminal Type:
Micro-Connector
NEMA Standard as Enclosure Rating:
1, 4, 12, 13
Body Orientation:
Right Angle

IN STOCK: 39

Ships today, if you order in

MOQ for out of Stock Qty: 13

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
1
$72.81
5
$51.16
10
$48.10
13
$47.88
25
$46.63
38
$44.96
50 +
$44.75
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides
