SDX05D4 by honeywell

SDX05D4

Honeywell

Pressure Sensor 0psi to 5psi Differential/Gage 6-Pin DIP-D4 ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

Board Mount Pressure Sensors are uncompensated, unamplified sensors that measure absolute and gauge pressures in medical and industrial applications. Honeywell Sensors are used in dialysis equipment, HVAC devices, data storage, industrial machinery, pumps, and robotics.

This Honeywell Board Mount Pressure Sensor is small in size and has precision temperature compensation. It has high impedance for low power applications. SDX05D4 Honeywell Sensor is used in medical equipment and computer peripherals. This Pressure Differential Sensor is also used in pneumatic controls and HVAC.

Product Highlights:

  • Low Noise
  • High Impedance for Low Power Applications
  • Prime Grade Available (SDXxxxyy-A)
  • Low Cost DIP
  • Precision Temperature Compensation
  • Calibrated Zero & Span
  • Small Size

Search Keywords: SDX05D4

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
SDX05D4
RoHS:
Yes
HTS:
90262000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Mounting:
PCB Through Hole 90 °
Accuracy:
±1 %
Device Pressure Type:
Differential
Operating Pressure Range:
0 to 5 psi
Media:
Air,Gas
Output Voltage:
0 to 60 mV
Response Time:
0.1 mS
Typical Operating Supply Voltage:
12 V
Operating Temperature:
-40 to 85 °C
Dimension:
19.56 x 13.97 x 10.92 mm

IN STOCK: 2,714

Ships today, if you order in

Factory Lead-Time 12 Weeks

Price (CAD)

Qty
Unit Price
1
$260.061
5
$256.002
7
$254.716
13
$253.462
19
$252.190
25 +
$250.919
Suppliers Standard Package
Log in for special pricing
Click for Quote

Tools/3D Models

Product Guides
