SS41 by honeywell

SS41

Honeywell

Hall Effect Sensor - Position - Digital - Bipolar - SS40 Series - Sink Output - 0.15 V out - 4.5 to 24 Vdc - 3 Pins - Through Hole. ...

Datasheet
RoHS Compliant
Box Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The SS41 is a bipolar hall-effect sensor for respond to alternating North and South poles. A built-in regulator provides stable operation over 4.5VDC to 24VDC supply voltage range and internal circuitry prevents sensor damage in case the supply voltage polarity is accidentally reversed. The SS41 hall-effect sensors are small, versatile digital hall-effect devices that are operated by the magnetic field from a permanent magnet or an electromagnet. The open-collector sinking output voltage is easily interfaced with a wide variety of electronic circuits.

Product Highlights:

  • Sensitive magnetic characteristics
  • Operating speed from 0 kHz to over 100 kHz
  • Small size
  • Reverse power polarity protection
  • Current sinking output

Search Keywords: SS41

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
SS41
RoHS:
Yes
HTS:
85423900
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
Box
Magnetic Type:
Bipolar
Maximum Output Current:
20 mA
Mounting:
PCB Through Hole
Minimum Magnetic Sensor Release Point:
-40(Typ) Gs
Maximum Magnetic Sensor Operating Point:
40(Typ) Gs
Output Type:
Sink
Output Driver:
NPN
Product Type:
Digital
Dimension:
4.1 x 1.5 x 3 mm
Typical Operating Supply Voltage:
4.5 to 24 V
Termination Type:
PC Pins
Operating Temperature:
-55 to 150 °C

IN STOCK: 44,558

Can Ship immediately

Minimum Order: 5

Factory Lead-Time 6 Weeks

Price (CAD)

Qty
Unit Price
5
$9.708
25
$7.197
100
$6.738
250
$6.707
500
$6.539
1,000 +
$6.509
