V3-1001 by honeywell
Image is representational - see manufacturer specifications
Honeywell Authorized Distributor

V3-1001

MICRO SWITCH™ Miniature Basic Switches: V3 Series, Single Pole Double Throw (SPDT), 10 Amps, [6 - 14 oz] Operating Force, Silver Contacts, Meets MIL-S-8805 Requirement, Screw Termination ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

Snap Action Switches are electromechanical switch devices used to open or close an electric circuit at a rapid speed. They are activated by an external force that is applied to the actuator. Actuator styles available for snap action switches include lever, pushbutton, and roller. They are widely used as safety switches in elevators, door interlock on a microwave oven, vending machines, etc.

V3-1001 Snap Action Switch from Honeywell has a maximum pre-travel 1.2 mm and a minimum over-travel of 1.02 mm. This Honeywell Switch comes with an operating force of 3.89 N and a long mechanical life of up to 10000000 cycles.

Product Highlights:

  • The Honeywell Snap Action Switch has screw mounting
  • It has maximum movement differential of 0.41 mm
  • The Honeywell Switch comes with a pin plunger actuator
  • 1.11 N worth of release force

Search Keywords: V31001

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
V3-1001
Alias/AKA:
MS25253-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
85365009
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Mounting:
Through Hole
Pole Throw Configuration:
N/A
Switch Configuration:
N/A
Actuator Material/Style:
Pin Plunger
Contact Rating @ Voltage:
10 A
Maximum Movement Differential:
0.41 mm
Operating Force:
3.89 N
Termination Style:
Screw
Dimension:
34.6 mm x 10.2 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 3,402

Can Ship immediately

Minimum Order Quantity: 7

Factory Lead-Time 4 Weeks

Price (USD)

Qty
Unit Price
7
$30.09
10
$29.80
25
$29.50
50
$29.43
100
$29.36
250 +
$29.28
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request
