V7-1B17D8-263 by honeywell

V7-1B17D8-263

Honeywell

MICRO SWITCH™ Miniature Basic Switches: V7 Series, Single Pole Double Throw (SPDT), 4A 125 Vac, 90g Maximum Operating Force, Simulated Roller Lever, UL Recognized, CSA, and VDE Certified, Quick Connect Termination ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

Snap Action Switches are switch devices that are used to open or close an electrical circuit at a rapid speed. These devices are also known as micro switches and work with lever, pushbutton, and roller actuators. They are generally used in appliances, vending machines, timing devices, office equipment, test instruments, valves, and pressure switches, among others.

V7-1B17D8-263 Snap Action Switch from Honeywell is a miniature-type basic switch. Specifically designed for 100K operations at a full load, this Honeywell Switch is ideal for higher cost-of-failure applications. The current rating of this Honeywell Snap Action Switch ranges from 0.1 A to 25 A.

Product Highlights:

  • Best suited for higher cost-of-failure applications
  • Designed for 100K operations at a full load or 10M for mechanical life
  • World-wide package size acceptance
  • Current rating ranges from 0.1 A to 25 A
  • UL/CSA and ENEC approvals

Potential Applications:

  • Appliances
  • Vending machines
  • Timing devices
  • Office equipment
  • Computer/business equipment
  • Test instruments
  • Medical/dental equipment
  • Communications equipment
  • HVAC equipment
  • Manually operated devices
  • Valves
  • Gaming equipment
  • Pressure switches

Search Keywords: V71B17D8263

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
V7-1B17D8-263
RoHS:
Yes
HTS:
85365080
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Package Type:
Tray
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Steel/Simulated Roller Lever
Contact Rating @ Voltage:
248.57@(CSA/UL) A
Maximum Movement Differential:
0.75 mm
Operating Force:
0.88 N
Termination Style:
Quick Connect
Dimension:
28.8 x 10.16 x 15.9 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 0

Minimum Order: 5

Factory Lead-Time 5 Weeks

Price (USD)

Qty
Unit Price
5
$3.039
50
$2.050
200
$1.844
400
$1.730
600
$1.700
1,000
$1.689
2,600
$1.679
5,000 +
$1.669
Suppliers Standard Package
Log in for special pricing
Click for Quote
Older Equivalent
V3L-3282-D8
V3L-3282-D8
VIEW PRODUCT
