V7-3S17D8-022 by honeywell

V7-3S17D8-022

Honeywell

MICRO SWITCH™ Miniature Basic Switches: V7 Series, Single Pole Double Throw (SPDT), 0.1 A 125 Vac, Gold-Plated Contacts, 35,6 mm [1.4 in] Straight Lever Actuator, 30 g [1.06 oz] Maximum Operating Force, 2,9 mm [0.11 in] Mounting Holes, -40 °C to 85 °C [-40 °F to 185 °F] Temperature Range, 4,75 mm x 0,51 mm [0.187 in x 0.02 in] Quick Connect Termination, UL, CSA ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The HONEYWELL part V7-3S17D8-022 is a high-quality MICRO SWITCH„¢ Miniature Basic Switch from the V7 series. This switch features a Single Pole Double Throw (SPDT) configuration, allowing for versatile usage in a variety of applications. With gold-plated contacts, this switch ensures reliable and long-lasting performance. The switch comes with a straight lever actuator that measures 35.6 mm (1.4 in) in length, providing a convenient and easy-to-use interface. Its maximum operating force is 30 g (1.06 oz), offering a comfortable and responsive operation. With 2.9 mm (0.11 in) mounting holes, this switch is easy to install and secure in place. It has a wide temperature range of -40 °C to 85 °C (-40 °F to 185 °F), making it suitable for use in various environments.The switch features a quick connect termination with dimensions of 4.75 mm x 0.51 mm (0.187 in x 0.02 in), ensuring easy and efficient electrical connections. It is UL and CSA certified, meeting industry standards for safety and reliability.

Potential Applications:

  • Appliances
  • Vending machines
  • Timing devices
  • Office equipment
  • Computer/business equipment
  • Test instruments
  • Medical/dental equipment
  • Communications equipment
  • HVAC equipment
  • Manually operated devices
  • Valves
  • Gaming equipment
  • Pressure switches

Search Keywords: V73S17D8022

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
V7-3S17D8-022
RoHS:
Yes
HTS:
8536509065
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Package Type:
Tray
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Steel/Straight Lever
Contact Rating @ Voltage:
0.1@125VAC@(CSA/UL) A
Maximum Movement Differential:
0.76 mm
Operating Force:
0.29 N
Termination Style:
Quick Connect
Dimension:
38.99 x 10.16 x 26.14 mm
Body Orientation:
Straight
IP Rating:
N/A
