V7-7B17D8-201 by honeywell

V7-7B17D8-201

Honeywell

MICRO SWITCH™ Miniature Basic Switches: V7 Series, Single Pole Double Throw (SPDT), 4A 125 Vac, 10 oz Maximum Operating Force, Roller Lever Actuator, UL Recognized, CSA, and VDE Certified, Quick Connect Termination ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

Snap Action Switch, also known as a micro switch is a kind of momentary contact switch. These switch devices work with lever, pushbutton, and roller actuators. Snap action switches are widely used in timing devices, office equipment, gaming equipment, manually operated devices, medical and dental equipment, computer and business equipment, test instruments, HVAC equipment, communications equipment, valves and pressure switches.

V7-7B17D8-201 Snap Action Switch from Honeywell has UL/CSA and ENEC approvals and is best suited for higher cost-of-failure applications. It is designed for 100K operations at a full load and a current rating that ranges from 0.1 A to 25 A.

Product Highlights:

  • Best suited for higher cost-of-failure applications
  • Designed for 100K operations at a full load or 10M for mechanical life
  • World-wide package size acceptance
  • Current rating ranges from 0.1 A to 25 A
  • UL/CSA and ENEC approvals

Potential Applications:

  • Appliances
  • Vending machines
  • Timing devices
  • Office equipment
  • Computer/business equipment
  • Test instruments
  • Medical/dental equipment
  • Communications equipment
  • HVAC equipment
  • Manually operated devices
  • Valves
  • Gaming equipment
  • Pressure switches

Search Keywords: V77B17D8201

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
V7-7B17D8-201
RoHS:
Yes
HTS:
8536508000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Package Type:
Tray
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Oil Bronze/Steel/Roller Lever
Contact Rating @ Voltage:
248.57@(CSA/UL) A
Maximum Movement Differential:
0.33 mm
Operating Force:
2.78 N
Termination Style:
Quick Connect
Dimension:
38.99 x 10.16 x 29.79 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 2,567

Can Ship immediately

Minimum Order: 5

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
5
$3.348
50
$2.668
200
$2.544
400
$2.245
600
$2.225
1,000
$2.122
2,600
$2.101
5,000 +
$2.091
